Finolex Flamegard FR-LSH Wire (200/300 meter)

Finolex Flamegard FR-LSH Wire is a top-tier electrical cable range engineered for advanced fire protection and low-smoke emission. Built with 99.97% pure electrolytic grade multi-stranded copper, it delivers superior electrical conductivity across light-load and heavy-duty circuits for residential, commercial, and industrial use.

Unlike basic PVC wires, the FR-LSH compound restricts heat transmission and keeps visibility intact during emergencies by cutting smoke generation by more than 60%, while suppressing toxic halogen gases. The range spans five wire thicknesses (1.0 to 6.0 sq mm) and five colours, making it suitable for everything from LED lighting circuits to line-phase routing for ACs, HVAC systems, and main distribution boards.

Key Features

Advanced Flame Retardant: Aggressively resists flame spread during a fire

Low Smoke & Halogen-Free: Drastically reduces smoke density and toxic emissions

100% Pure Copper: Electrolytic grade multi-stranded core conductors

ISI Certified Grade: Fully compliant with IS: 694 electrical standards

High Voltage Capacity: Safely handles installations up to 1100V

Technical Specifications

Technical Specifications (Quick Reference)

Specification
Details

Brand
Finolex

Size Options
1.0 / 1.5 / 2.5 / 4.0 / 6.0 sq mm

Coil Length
300 m (1.0, 1.5, 2.5 sq mm) / 200 m (4.0, 6.0 sq mm)

Colour Options
Red, Black, Blue, Green, Yellow

Voltage Rating
1100 V

Rated Current
Varies by thickness ? see Variant Comparison below

Material & Finish
99.97% Pure Stranded Copper

Insulation Material
Flame Retardant Low Smoke Halogen (FR-LSH) PVC

Number of Cores
1 Core (Single Core)

Certification
IS: 694

Usage Suitability
Residential / Commercial / Industrial

Variant Comparison ? Thickness Options

Thickness
Coil Length
Best for

1.0 sq mm
300 m
Light-load circuits, household LED lighting, fan wiring

1.5 sq mm
300 m
Standard domestic wall outlets, moderate light loads

2.5 sq mm
300 m
Power sockets, microwave lines, small geysers

4.0 sq mm
200 m
Heavy appliances like 1.5?2 Ton ACs, main distribution

6.0 sq mm
200 m
High-capacity industrial machines, main board connections

Available Colours
Every thickness in the Finolex Flamegard FR-LSH Wire range is available in 5 colours ? Red, Black, Blue, Green, and Yellow ? for standard phase, neutral, and earthing colour-coding.

Core Recommendations for Safe Installation

Installation Best Practices

Conduit Pulling: Pull wire carefully through conduits to avoid tearing the insulation

Load Calculation: Match the wire cross-section strictly with your appliance’s power wattage

Terminal Connections: Always use crimped lugs or tight terminal pins to avoid sparking

Colour-Coding Routine: Use specific colours systematically for phases, neutral, and earthing
