Ebco Door Viewer DV1 is a premium brass peephole offering 165? wide-angle visibility for enhanced home and office security. This door viewer allows you to safely identify visitors before opening the door, providing peace of mind for residential and commercial properties.
Suitable for doors with thickness ranging from 25mm to 60mm, the DV1 requires a 25mm diameter installation hole. Available in brushed steel and antique finishes, this door viewer combines functionality with aesthetic appeal to complement your door hardware.
Technical Specifications (Quick Reference)
Specification
Details
Manufacturer
EBCO
Model Code
DV1
Viewing Angle
165? wide-angle
Compatible Door Thickness
25mm to 60mm
Installation Hole Size
25mm diameter
Material
Brass
Finish Options
Brushed Steel, Antique
Recommended Applications
Residential Entry Doors: Perfect for home front doors, main entrances, and apartment doors
Office and Commercial Spaces: Ideal for office doors, meeting rooms, and restricted access areas
Hotel Rooms: Essential security feature for hotel and guest room doors
Rental Properties: Great for landlords looking to enhance tenant security
Security Upgrades: Excellent addition to existing door security systems
Installation Guidelines
Mark Installation Point: Choose the viewing height (typically 1500-1600mm from floor) and mark the center point on the door
Drill Hole: Using a 25mm drill bit, carefully drill through the door at the marked point
Insert Viewer: Insert the exterior lens from outside and the interior eyepiece from inside
Tighten and Secure: Screw the two parts together until firmly secured and test the viewing angle
