Bosch Expert 5-Inch Segmented Universal Diamond Cutting Blade (2608615111) is a premium 8-segment diamond cutting disc for fast material removal across a wide range of construction materials – ceramic tiles, porcelain, marble, natural stone, concrete, brick, and general masonry. The advanced resin bond matrix balances cutting speed and blade longevity. Segmented design allows faster heat dissipation than a full-rim blade, making it well suited for dry cutting applications. Permanent laser-etched labels on the steel core retain all safety and technical markings throughout the full blade life. Fits standard 5-inch angle grinders and marble cutters via a 22.23mm bore.
Key Features
Segmented design – fast cutting: 8 segments allow rapid heat dissipation for sustained dry cutting without overheating
Advanced resin bond matrix: Optimises the balance between cutting speed and total blade service life
Permanent laser-etched labels: Safety and technical data embedded into the steel core – never fades or peels
22.23mm standard bore: Fits all standard 5-inch angle grinders and marble cutters
Wide material compatibility: Cuts ceramic, porcelain, marble, stone, concrete, brick, and masonry
Technical Specifications
Technical Specifications (Quick Reference)
Specification
Details
Brand
Bosch Expert
Model Number
2608615111
Blade Type
Segmented Diamond Cutting Disc
Outer Diameter
125 mm (5 inch)
Bore Size
22.23 mm
Segment Height
12 mm
Number of Segments
8
Compatible Tools
5-inch angle grinders, tile cutters, marble cutters
Item Weight
163 grams
Usage and Safety Guidelines
Important – Read Before Use
Power off before fitting: Always disconnect the angle grinder from the power source before installing or removing the blade
Check direction arrow: Mount the blade with the rotation arrow matching the tool’s spindle direction
Use the correct guard: Always operate with the tool’s safety guard fitted – never remove it
Wear PPE: Safety goggles, N95 dust mask, heavy-duty gloves, and ear protection are mandatory – dry cutting generates fine silica dust
Let the tool reach full RPM before contacting the material. Apply steady, light pressure – do not force the blade
Best paired with: Bosch GWS series 5-inch angle grinders for maximum torque and clean cuts
Recommended Applications
Where this blade fits best
Ceramic and porcelain tiles: Fast, precise cuts for floor and wall tile installations
Marble and natural stone: High-density slabs and stone blocks for countertops and cladding
Concrete and masonry: General brickwork, block cutting, and site masonry tasks
Synthetic stone: Manufactured stone panels and composite masonry materials
Why Buy from HomeRun?
Authentic Bosch Product: Verified genuine Bosch Expert accessory
60-Minute Bangalore Delivery: Express delivery to active service zones – ideal for tiling and masonry projects
Project-Friendly Availability: Single-unit ordering – no forced bulk minimum
